Deliver an electrifying 400 kW of power while supporting dual vehicle charging with EVBox Troniq High Power, the first standalone 400 kW station tested and proven in the field.
Ideal for high-traffic locations, EVBox Troniq High Power is designed to provide the fastest charging experience for drivers. Businesses benefit from the increasing demand for fast charging and a driver's willingness to pay more for the convenience.
Thanks to smart charging capabilities that intelligently distribute power, EVBox Troniq High Power delivers one of the fastest charging experiences on the market while optimizing power consumption and avoiding costly grid upgrades.
Back-end agnostic and built on open standards, EVBox Troniq High Power integrates seamlessly with your existing charging management software. With Autocharge and multiple payment options, this charging station is perfect for on-the-go locations.
Thanks to its modular design, new base frame, and guiding template, installers can quickly connect and mount stations, reducing errors and delays.
The new contactless payment terminal with a pin pad enables fast and convenient payments while supporting most credit and debit cards.
The upgraded flush screen delivers improved resistance to damage and dirt buildup and a better experience in terms of touch, interaction, and responsiveness.
The new front-facing connectors offer convenience and ease of use while reducing the station's overall footprint, making it a practical solution for any location.
Showcase your unique brand and style with our complimentary wrapping and painting options. Do it yourself or let our team handle it for you.
Delivering 375 A continuously and up to 500 A for more than 30 min at 20°C, EVBox Troniq High Power is a versatile and reliable solution for a wide range of use cases.
“We’re looking forward to partnering with EVBox and piloting this new charger, which we expect will become best-in-class. EVBox and Fastned will work closely together in optimizing the user experience and the communication between the charger and Fastned’s backend system. We're committed to continuously improving charger speed and reliability to provide our customers with the best experience and give freedom to electric drivers.”
Roland van der Put
Head of Charging Technology at Fastned
“As a real estate company, it is important for us to actively facilitate the change toward a greener future. When choosing a vendor for our charging initiative, there were key selection criteria for us that the vendor had a robust product and that they shared the same enthusiasm and passion for sustainability—EVBox checked all boxes.”
Manager at Ragde Charge
“We are happy to work with the City of Amsterdam to make the city greener and contribute positively to its 2030 ambitions. Having EVBox Troniq Modular in such a booming area of Amsterdam, our hometown makes this installation a personally important one for us. We hope that we can set an example for other cities around Europe and the world.”
VP Commercial Support at EVBox
EVBox Troniq High Power comes with two CCS2 connectors to charge 2 cars simultaneously. Its modular architecture maximizes uptime while its scalability enables three power outputs: 320, 360, and 400 kW.
DC charging: CCS2 up to 500 A / 920 V at 20°C
1-phase (32 A) or 3-phase (16 A or 32 A), 230V - 400V Split phase (30 A), 208 - 240V (3rd gen only available)
Upgradable power modules
Easy to upgrade in 40 kW increments
Body: Traffic white (RAL 9016)
Other: Black grey (RAL7021), Jet Black (RAL9005)
Powder coated steel
15" (38 cm) Flush LCD color touchscreen, sunlight readable
20 supported languages
Operating temperature range
-25°C to +40°C (+55°C with derating)
IP54 / IK10
4G/LTE (3G/2G fallback), Ethernet
RFID and optional payment terminal
OCPP 1.6J, ready for update to OCPP 2.0.1
EVBox Troniq High Power is hardware-ready to support ISO 15118, the latest EV charging protocol that enables future EV technologies like Plug & Charge.
EVBox Troniq High Power is hardware-ready to support OCPP 2.0.1 enabling the latest security standards and more sophisticated station management.
